Cinnamon and his friends on the cycle path
Programming level 1
Puppet theatre
P1
How to build
The robot
- Building the characters in the scene
- Their head, arms and mouth can move axially
- All the characters are movable
P1
Static figures
P1
Programming level 2
Bike trip
P2
How to build
The robots
a.) Friends go on a bike ride
- kids ride their bikes on the cycle path
- Cinnamon sitting in the basket
b.) Cinnamon makes magic
- raises its hand with a servomotor
- the bike rises with the balloon (it moves up a slope with the help of a cogwheel)
P2
The robots
P2
P2
Programming level 3
Respecting traffic rules
P3
How to build
The robots
a.) placing the bike on the robot platform
- Moving forward with DC motors
b.) When it reaches a black line, it stops (end of cycle path)
- detects the black line using 1 IR
c.) cars driving on the road
- building a small car with gears
- building a line-following robot car (2 downward facing IR)
d.) traffic light
- Using 3 LED
- the 3 LEDs flash one after the other
P3
The robots
P3
P3
Programming level 4
First aid
P4
How to build
The robots
a.) the cyclist has an accident
- one bike rings (1 Buzzer) when it detects an obstacle (1 touch sensor) and stops
b.) the cyclist detects an object but can no longer stop and falls
- 1 with servomotor tilted to the right
- the other cyclist makes a phone call
c.) The ambulance arrives
- 4 touch sensor to control the ambulance (forward, left, backward, right)
- 2 LEDs to indicate if you are turning left or right
P4
The robots
